全鋼子午胎胎坯內外噴涂生產線
設備用途 Equipment use
用于全鋼子午胎胎坯的隔離劑噴涂
It is used in the dusting agent spray painting of all-steel radial tyre.
設備特點Equipment characteristics
進入輥道輸送機、胎坯定中裝置、升降裝置、輸出輥道輸送機、旋風除塵裝置等組成。
It consists of roller entrance & conveying machine, green tyre centering unit, hoisting unit, output roll conveyor machine and rotary dedusting unit etc.
|
主要技術參數Main technical parameters |
|
序號 № |
胎坯噴涂方式
Green tyre spray painting method |
胎坯適用規格Applicable green tyre specification |
坯胎適用外徑
Applicable green tyre outer diameter |
|
1 |
內噴/外噴
Inner spray painting/ outer spray painting |
18〞-24.5〞 |
Ф900mm-Ф1250mm |
|
2 |
坯胎適用高度
Applicable green tyre height |
坯胎最大重量
Maximum green tyre weight |
胎坯內噴涂時間
Coating time of inner spray painting |
|
3 |
200mm-500mm |
Max.125kg |
內噴3-5秒Inner spray painting 3-5s |
|
4 |
胎坯外噴涂時間
Green tyre outer spray painting time |
機械手旋轉工位
Manipulator rotating station |
胎坯噴涂日產量
Daily output capacity of green tyre spray painting |
|
5 |
外噴3-6秒
Outer spray painting 3-6s |
5工位 5 station |
2400條/日2400pcs/day |
